How to Install and Unload the Complete Transmission - The transmission system is a system used for the conversion of torque and speed (speed) of the engine into torque and different speeds to be forwarded to the final drive. This conversion changes the high rotation speed to be lower but more powerful, or vice versa.
Once you understand about the transmission system, let's move on to the next section which is unloading and installing the transmission.
In this article will be divided into 2 stages namely the first way of unloading the transmission and the second course after dismantling, the installation of transmission.
How to Unload and Install Transmission
Of course if we are going to disassemble and install the necessary transmission tools work and a good preparation.
Initial Step Start Up Loading Tranmisi
The process of dismantling begins with the preparation of necessary tools and equipment. This is so that the time used is not wasted in vain due to looking for equipment and tools.
Tools and equipment needed are:
Jack stand or buffer and car jack
Transmission Jack
This jack is a kind of hydraulic, but there are also using a thread or round. This tool is a vital tool in the process of dismantling or installation of transmission. Because of the time and position of the transmission will trouble the process of installation or dismantling. In addition, the safety of workers will be very dangerous without the existence of the transmission jack, as well as the accuracy of transmission installation.
In addition to these two things, there are still more necessary tools, among others:
Vet gravit and duster / majun.
The transmission lubricant oil pump and its lubricating oil.
Toolbox containing the required key
Work lights for lighting considering the transmission position that tends to be under the vehicle.
Old lube oil reservoir.
After all the preparations have been done, we are now proceeding to the demolition stage. Other interesting articles can be studied in Complete Annual Plant Example along with Images.
Transmission Dismantling Stage
a) Release the negative battery terminals, this is to maintain the possibility of short circuit while working.
b) Lift the car using the jack and install a high lift jackstand to provide free space for workers as well as the process of unloading and installing the transmission.
c) Remove the rubber stick cover / lever / transmission transfer handles. See figure 16 below. By removing the bolt.
remove the bolt.
Shifting system on the steering wheel
d) Remove the transmission shifting handle by removing the bolt and lifting it out. See the following picture.
Release of transmission fastener bolts
e) Remove the starter motor, ie disconnect the cords and bolts tie.
f) Remove the transmission lubricating oil, by opening the tap bolt, and preparing the lube oil reservoir. When finished, put the tap bolt back and remove the lubricating oil container, not to spill. If it spills first.
g) Unplug the propeller head, so that the installation is not wrong before marking it off. As shown in the picture.
h) Disconnect the speedometer cable and reverse lamp cable from the terminal.
i) Disconnect the clutch cable from the release lever. View image.
Unplug the propeller shaft
Unplug the clutch
j) Remove grips and exhaust clamps associated with the transmission.
k) Attach the transmission jack well, if necessary tie with bolt or chain available. This prevents transmission from falling when the fastener bolt is removed. Consider the following picture.
The position of the jack jack
l) Remove the transmission mounting.
m) Loosen transmission home fastener bolts. Note whether the transmission remains flat or not, if it is tilted like image 20, then raise the jack.
n) When the transmission is properly positioned, remove the transmission bolt bolt. Again pay attention to the flat position of the transsmission.
o) Pull the transmission towards the rear of the car, until the end of the transmission pivot shaft pivot, and then lower the transmission boots slowly until estimated when pulled out from under the car does not concern.
p) Lower the transmission from the jack.
Transmission Installation Stage
a) Lubricate using a heat-resistant vet graphite or vet on a pilt bearing on a fly wheel, a bearing boss's delivery line, and a transmission shaft groove. Note the picture 19. beside that also at the end of the clutch cable.
b) Install transmission on the transmission jack, as before the transmission position should be flat, especially the transmission input shaft. And the transmission fastly ties to the jack in the position at the time it is attached.
c) Put the jack and transmission under the car kekolong.
d) Raise the jack to the right input shaft with the pilot pad.
e) Push the transmission slowly to adjust the transmission input pivot tip on the pilot bearing on the fly wheel. Once fitted, push it back until the transmission home sits easily. In this process should never be forced by pressing the bolt prngikat home transmission.
f) Install bolts and mounting the transmission. Refresh according to the hardening moment in the manual.
g) Replace the starter motor along with the cable.
h) Install the propeller shaft according to the mark made.
i) Install the speedometer cable and retract cable and exhaust clamp.
j) Contents of transmission lubricating oil.
k) Attach the clutch cable and stel height and clutch pedal freedom.
Pedal height = 150.8 mm, and freedom = 20-35 mm.
l) Install the transmission shift handle along with the rubber cover.
m) Lower the vehicle from the jack stand.
n) Turn on the car, try clutch adjustment and transmission work.
o) Clean the equipment and equipment used.
well that's my explanation may be useful.
